Alloy Stainless Steel
Created with Pixso. Precision steel pipe 631 alloy stainless steel pipe High temperature alloy pipe

Precision steel pipe 631 alloy stainless steel pipe High temperature alloy pipe

Model Number: 631
MOQ: 1ton
Price: Negotiable
Delivery Time: 5-15 days
Payment Terms: T/T L/C
Detail Information
Place of Origin:
China
Weighing Method:
Actual Weighing
Is It Tailings?:
No
Application:
Industrial Construction Machinery And Automobile Hook Tube
Brinell Hardness:
≤290
Customized Processing:
Yes
Outer Diameter:
6.35mm
Wall Thickness:
0.89mm
Packaging Details:
Waterproof paper + steel belt
Supply Ability:
3000 tons/week
Product Description

‌631 alloy stainless steel‌, also known as 0Cr17Ni7Al or SUS631, is a semi-austenitic precipitation hardening stainless steel. Its chemical composition includes carbon (C) ≤0.09%, silicon (Si) ≤1.00%, manganese (Mn) ≤1.00%, sulfur (S) ≤0.030%, phosphorus (P) ≤0.035%, chromium (Cr) 16.00~18.00%, nickel (Ni) 6.50~7.75%, copper (Cu) ≤0.50% and aluminum (Al) 0.75~1.50%.

Performance characteristics
High strength and high hardness‌: After aging treatment, its tensile strength is significantly improved, for example, after aging treatment at 565℃, the tensile strength can reach 1140 MPa; after aging treatment at 510℃, the tensile strength can reach 1230 MPa‌.
‌Good corrosion resistance‌: It can maintain good performance in a variety of corrosive environments and is suitable for application scenarios that require high corrosion resistance‌.
‌Fatigue resistance‌: It is not easy to suffer fatigue damage under repeated stress, and is suitable for parts that need long-term stable work‌.

Application areas
‌Aerospace‌: Used to manufacture aircraft engine parts, landing gear, structural parts, etc. ‌Medical equipment‌: Used for surgical instruments, implants and other parts that require high strength and corrosion resistance‌. ‌Automobile manufacturing‌: Used to manufacture high-performance automotive parts such as engine parts and transmission systems‌. ‌Other industrial applications‌: It is also used in petrochemical, machinery, electricity, energy and other fields‌.


Product ‌631 alloy stainless steel‌
Diameter ( Diameter: 3mm~800mm )
 Length 1~ 12meters
Material 201.202, 304, 304L, 316, 316L, 321, 431, 416, 630,
17-4PH, S31803 (F51), S32205 (F60), S32750 (F53), S32760 (F55),
Standard ASTM 276, ASTM A564, ASTM A582, ASTM A484
Surface Bright, peeled, CNC machined, polished, or black etc,
 Diameter tolerance H9, H11, H13, K9, K11, K13 etc…as per clients' request etc
Length tolerance 0/+50mm
Finishing Solution treated
Application Shipbuilding industry, marine shaft, propeller shaft, transmission shaft bolt & nuts, machine-made industry, food industry, paper mill equipment.

Precision steel pipe 631 alloy stainless steel pipe High temperature alloy pipe 0

Q1.Can I have a sample order for stainless steel products?
A:Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2.What about the lead time?
A:Sample takes 3-5 days, production time takes 7-15days  for order quantity more than 28tons.

Q3.Do you have any MOQ limit for stainless steel products order?
A:Low MOQ, 1pc for sample checking

Q4.How do you ship and how long does it take to arrive?
A:For samples, we usually ship by DHL, UPS, FedEx or TNT, It usually takes 3-5 days to arrive. Airline and sea shipping are also optional. For mass products, ship freight is preferred.

Q5.Is it OK to print my logo on the product?
A:Yes.OEM and ODM can be provided for us.

Q6:Do you provide guarantee for the product?
A:Yes, we provide 5-10 years warranty for our products.

Q7:How to deal with the failure?
A: First of all, our products are produced under a strict quality control system, and the defective rate will be reduced by 0.2%.
